Opti Electrostatic Powder Coating Control select Box opti Spray Gun for GM02
Specifications
| Return Shipping Will Be Paid By | Seller |
| All Returns Accepted | Returns Accepted |
| Item Must Be Returned Within | 30 Days |
| Brand Name | LISM |
| Brand | Unbranded |
| Origin | Mainland China |
| Application | Paint Spray Gun |
| Certification | none |
| Model Number | GEMA01 |
| UPC | Does not apply |
Electrostatic Spraying Opti Electrostatic Powder Coating Control select Box opti Spray Gun for GM02 Welcome everyone to buy our products, and you can enjoy extra discounts when you become a store fan. Electrical data Nominal input voltage 100V240VAC Frequency 50-60Hz Connected load (without vibrator) 40 VA Nominal output voltage (to the gun) eff.10 V Nominal output current (to the gun) max. 1.2 A Connection for rinsing function (valve) 24 VDC max. 3 W Temperature range 0°C - +40°(+32°F - +104°F) Max. surface temperature 100 °C (+212 °F) Approvals II 3 D IP54 120 °C Pneumatical data MAX.input pressure 10bar MIN.input pressure 6bar Input pressure (Dynamic based on pressure regulator setting) 5.5 bar / 80 psi Max.water vapor content of the compressed air 1.3g/Nm³ Max.oil vapor content of the compressed air 0.1mg/Nm³ Max.compressed air consumption 11Nm³/h
